Traxxas X-Maxx Ultimate Blue (X-Truck) - 77097-4-BLUE

Some vehicles may have been removed from their box for display purposes only - they have NOT been turned on

Traxxas X-Maxx® Ultimate

Model 77097-4: Fully assembled, Ready-To-Race® monster truck with TQi™ 2.4 GHz radio system, VXL-8s™ brushless power system, painted clipless body, and premium aluminum upgrades.

What’s In The Box

• X-Maxx® Ultimate Ready-To-Race® model with Traxxas Big Block™ brushless motor
• VXL-8s™ waterproof electronic speed control with integrated telemetry
• TQi™ 2.4 GHz radio system with factory-installed wireless module
• Quick Start Guide
• High-quality maintenance tools

What You’ll Need

• Batteries: Dual 4-cell Traxxas Power Cell LiPo batteries recommended, or Dual 4s Completer Pack 2997
• Charger: Traxxas EZ-Peak® Live Dual 4s-capable charger 2973 recommended
• Transmitter Batteries: Four AA alkaline batteries

Features

• High-Performance Aluminum Upgrades: 6061-T6 aluminum C-hubs, steering blocks, rear hub carriers, differential housings, and motor mounts.
• VXL-8s™ Waterproof ESC: 8s LiPo-compatible speed control with built-in cooling fan, machined heat sinks, 10-gauge silicone wire, protection circuits, LED status lights, and integrated telemetry.
• Velineon® 1200XL Brushless Motor: 4-pole 1275 Kv motor with 5 mm output shaft, aluminum heat sink, and dual cooling fans.
• Speed: 50+ mph with two 4s LiPo batteries and optional gearing, sold separately.
• Traxxas Stability Management®: Helps prevent spinouts and loss of control, with transmitter-adjustable assistance from off to 100%.
• TQi™ Radio System: 2.4 GHz 2-channel radio with factory-installed wireless module, telemetry sensors, 5-channel receiver, fail-safe security, telemetry ports, and 30-model memory.
• Clipless Body Mount System: Allows quick one-handed installation and removal with a pivoting rear latch, no body posts or clips, and reinforced protection.
• 8s Driveline: Full-time shaft-driven 4WD with hardened steel gears, heavy-duty steel CV driveshafts, steel differential output cups, aluminum center driveshaft, aluminum stub axles, torque-biasing center drive, 24 mm splined wheel hexes, and sealed fluid-filled differentials.
• Fixed Motor Mounting System: Rigid aluminum motor mounts with preset gear mesh adjustments and separate motor retention.
• Heavy-Duty Modular Chassis: Composite chassis with interlocking bulkheads, rear-mounted motor support, sealed driveline, and easy component access.
• Snap-Lock Battery Retention: Clip-free battery hold-downs pivot for access, adjust for battery size, and integrate into the chassis top brace for added stiffness.
• Bumpers: Front rubber impact bumper, lower front and rear skid plates, and integrated nerf bars for side impact resistance.
• Steering: 6061-T6 aluminum steering bellcranks, 2085RL high-output metal-gear servo, double-shear aluminum servo horn, and heavy-duty servo saver spring.
• Suspension: TUBES 7075-T6 aluminum front toe links, double-shear suspension points, steel suspension pins, secure pin retainers, optimized steering geometry, adjustable roll center, steel tie bars, and sealed bearings in exposed locations.
• Aluminum GTX™ Shocks: Machined threaded aluminum bodies with extra-large capacity, TiN-coated 5.2 mm shafts, integrated wiper seals, aluminum spring retainers, aluminum caps, and fixed shock locations.
• Wheels and Tires: Massive 8.4" Sledgehammer® belted tires with reduced ballooning, open tread blocks, 2-piece foam inserts, high-strength glue and bead design, and large dual-diameter wheels.
